![Hikvision DS-1006KI [32/37] Shortcut operation](/views2/1892089/page32/bg20.png)
DS-1200KI/1006KI Keyboard User Manual
DS-6900UDI Decoder User Manual
25
Step 1 Enter the Dome by RS-485 operation mode on the keyboard.
Step 2 Press the Num + CAM buttons to select the dome site.
Step 3 Use the joystick and operate the buttons on the keyboard panel to realize the corresponding
functions. Please refer to Chapter 1.4 Functional Buttons to check the description of the PTZ
control buttons.
Figure 4-17 DVR by RS-485
The address, baud rate, protocol and other parameters of RS-485 must be configured the same
with the dome’s RS-485 parameters.
Shortcut Operation 4.7
The device control via keyboard can be realized by shortcut operation.
Step 1 On the login interface, enter the user name and password to log in to the device.
Figure 4-18 Menu
Step 2 Use the joystick to select the Shortcut to enter the shortcut operation mode.
Step 3 Press the Num+DEV/MON/CAM/CAM-G/PRESET/PATROL/PATTERN/WIN/MULT/SCENE on
the keyboard buttons to realize the corresponding device operation and control.
