![Hikvision DS-1006KI [36/37] Chapter 6 specifications](/views2/1892089/page36/bg24.png)
DS-1200KI/1006KI Keyboard User Manual
DS-6900UDI Decoder User Manual
29
Specifications Chapter 6
Specification of DS-1200KI Table 6-1
Model
DS-1200KI
System
LCD screen
128 x 64 pixel screen
Joystick
4-axis joystick
Control mode
Network, RS-232, RS-422, RS-485
External
Interfaces
Network interface
1; 10 M/100 Mbps self-adaptive Ethernet
interface
Serial interface
1 RS-232, 1 RS-422, 1 RS-485
USB interface
1 × USB 2.0
General
Power supply
12 VDC
Consumption
≤ 4.5 W
Working temperature
-10 to +55° C (14 to 131° F)
Working humidity
10% to 90%
Dimensions (W × D × H)
435 × 193 × 110 mm (17.1 × 7.6 × 4.3 inch)
Weight
≤ 1 kg (2.2 lb)
Specification of DS-1006KI Table 6-2
Model
DS-1006KI
System
LCD screen
128 x 64 pixel screen
Joystick
4-axis joystick
Control mode
RS-232, RS-422, RS-485
External
Interfaces
Serial interface
1 RS-232, 1 RS-422, 1 RS-485
USB interface
1 × USB 2.0
General
Power supply
12 VDC
Consumption
≤ 4.5 W
Working temperature
-10 to +55° C (14 to 131° F)
Working humidity
10% to 90%
Dimensions (W × D × H)
435 × 193 × 110 mm (17.1 × 7.6 × 4.3 inch)
Weight
≤ 1 kg (2.2 lb)
