Step 2 Log in to keyboard via Web browser (https://ip address), and enter the Aux key settings page

(System Management>Aux Key Settings).

Step 3 Set the Aux key function to Screen Jointing.

Step 4 Click Save to save the settings.

Figure 4-6 Aux Key Settings

Step 5 In the keyboard operation mode,

1) Press the Num + DEV buttons to select the device ID.

2) Press the Num + AUX/F2 buttons to operate screen jointing for the video wall.

3) Press the Num + CAM buttons to select the input channel.

Figure 4-7 Video Wall Control by AUX Key

Picture Capture

The video picture from the camera can be captured and saved in U-flash disk through the keyboard

operation.

Step 1 Log in to keyboard via Web browser (https://ip address), and enter the Aux key settings page

(System Management>Aux Key Settings).

Step 2 Set the Aux key function to Capture.

Step 3 Click Save to save the settings.

Step 4 In the keyboard operation mode,

1) Press the Num + DEV buttons to select the device ID.
