uPC3 – rel 1.8 – 11/2021
31
Code
Description
Reset
Counter
Time [ms]
A000
Supply fan 1 - Ground fault
User reset
A001
Supply fan 1 - Inverter overheat
User reset
A002
Supply fan 1 - Motor overheat
User reset
A003
Supply fan 1 - Overload
User reset
A004
Supply fan 1 - Phase open
User reset
A005
Supply fan 1 - Overvoltage
User reset
A006
Supply fan 1 - Low voltage
User reset
A007
Supply fan 1 - Overcurrent
User reset
A008
Supply fan 1 - Inverter overload
User reset
A009
Supply fan 1 - Heat sink overheat
User reset
A010
Supply fan 1 - DC overload
User reset
A011
Supply fan 1 - Phase lost
User reset
A012
Supply fan 1 - Electric thermal
User reset
A013
Supply fan 1 - Parameter save error
User reset
A014
EC Supply fan 8 - Overvoltage
User reset
A015
Supply fan 1 - HW fault
User reset
A016
Supply fan 1 - Communication error
User reset
A017
Supply fan 1 - Cooling fan fault
User reset
A018
Supply fan 1 - Cut off
User reset
A019
Supply fan 1 - External fault A
User reset
A020
Supply fan 1 - External fault B
User reset
A021
Supply fan 1 - Option
User reset
A022
Supply fan 1 - Offline
User reset
A023
Supply fan 1 - Alarm
User reset
A024
Supply fan 2 - Ground fault
User reset
A025
Supply fan 2 - Inverter overheat
User reset
A026
Supply fan 2 - Motor overheat
User reset
A027
Supply fan 2 - Overload
User reset
A028
Supply fan 2 - Phase open
User reset
A029
Supply fan 2 - Overvoltage
User reset
A030
Supply fan 2 - Low voltage
User reset
A031
Supply fan 2 - Overcurrent
User reset
A032
Supply fan 2 - Inverter overload
User reset
A033
Supply fan 2 - Heat sink overheat
User reset
A034
Supply fan 2 - DC overload
User reset
A035
Supply fan 2 - Phase lost
User reset
A036
Supply fan 2 - Electric thermal
User reset
A037
Supply fan 2 - Parameter save error
User reset
A038
Supply fan 2 - HW fault
User reset
A039
Supply fan 2 - Communication error
User reset
A040
Supply fan 2 - Cooling fan fault
User reset
A041
Supply fan 2 - Cut off
User reset
A042
Supply fan 2 - External fault A
User reset
A043
Supply fan 2 - External fault B
User reset
A044
Supply fan 2 - Option
User reset
