uPC3 – rel 1.8 – 11/2021
32
A045
Supply fan 2 - Offline
User reset
A046
Supply fan 2 - Alarm
User reset
A047
Supply fan 3 - Ground fault
User reset
A048
Supply fan 3 - Inverter overheat
User reset
A049
Supply fan 3 - Motor overheat
User reset
A050
Supply fan 3 - Overload
User reset
A051
Supply fan 3 - Phase open
User reset
A052
Supply fan 3 - Overvoltage
User reset
A053
Supply fan 3 - Low voltage
User reset
A054
Supply fan 3 - Overcurrent
User reset
A055
Supply fan 3 - Inverter overload
User reset
A056
Supply fan 3 - Heat sink overheat
User reset
A057
Supply fan 3 - DC overload
User reset
A058
Supply fan 3 - Phase lost
User reset
A059
Supply fan 3 - Electric thermal
User reset
A060
Supply fan 3 - Parameter save error
User reset
A061
Supply fan 3 - HW fault
User reset
A062
Supply fan 3 - Communication error
User reset
A063
Supply fan 3 - Cooling fan fault
User reset
A064
Supply fan 3 - Cut off
User reset
A065
Supply fan 3 - External fault A
User reset
A066
Supply fan 3 - External fault B
User reset
A067
Supply fan 3 - Option
User reset
A068
Supply fan 3 - Offline
User reset
A069
Supply fan 3 - Alarm
User reset
A070
Supply fan 4 - Ground fault
User reset
A071
Supply fan 4 - Inverter overheat
User reset
A072
Supply fan 4 - Motor overheat
User reset
A073
Supply fan 4 - Overload
User reset
A074
Supply fan 4 - Phase open
User reset
A075
Supply fan 4 - Overvoltage
User reset
A076
Supply fan 4 - Low voltage
User reset
A077
Supply fan 4 - Overcurrent
User reset
A078
Supply fan 4 - Inverter overload
User reset
A079
Supply fan 4 - Heat sink overheat
User reset
A080
Supply fan 4 - DC overload
User reset
A081
Supply fan 4 - Phase lost
User reset
A082
Supply fan 4 - Electric thermal
User reset
A083
Supply fan 4 - Parameter save error
User reset
A084
Supply fan 4 - HW fault
User reset
A085
Supply fan 4 - Communication error
User reset
A086
Supply fan 4 - Cooling fan fault
User reset
A087
Supply fan 4 - Cut off
User reset
A088
Supply fan 4 - External fault A
User reset
A089
Supply fan 4 - External fault B
User reset
A090
Supply fan 4 - Option
User reset
