uPC3 – rel 1.8 – 11/2021
33
A091
Supply fan 4 - Offline
User reset
A092
Supply fan 4 - Alarm
User reset
A093
Return fan 1 - Ground fault
User reset
A094
Return fan 1 - Inverter overheat
User reset
A095
Return fan 1 - Motor overheat
User reset
A096
Return fan 1 - Overload
User reset
A097
Return fan 1 - Phase open
User reset
A098
Return fan 1 - Overvoltage
User reset
A099
Return fan 1 - Low voltage
User reset
A100
Return fan 1 - Overcurrent
User reset
A101
Return fan 1 - Inverter overload
User reset
A102
Return fan 1 - Heat sink overheat
User reset
A103
Return fan 1 - DC overload
User reset
A104
Return fan 1 - Phase lost
User reset
A105
Return fan 1 - Electric thermal
User reset
A106
Return fan 1 - Parameter save error
User reset
A107
Return fan 1 - HW fault
User reset
A108
Return fan 1 - Communication error
User reset
A109
Return fan 1 - Cooling fan fault
User reset
A110
Return fan 1 - Cut off
User reset
A111
Return fan 1 - External fault A
User reset
A112
Return fan 1 - External fault B
User reset
A113
Return fan 1 - Option
User reset
A114
Return fan 1 - Offline
User reset
A115
Return fan 1 - Alarm
User reset
A116
Return fan 2 - Ground fault
User reset
A117
Return fan 2 - Inverter overheat
User reset
A118
Return fan 2 - Motor overheat
User reset
A119
Return fan 2 - Overload
User reset
A120
Return fan 2 - Phase open
User reset
A121
Return fan 2 - Overvoltage
User reset
A122
Return fan 2 - Low voltage
User reset
A123
Return fan 2 - Overcurrent
User reset
A124
Return fan 2 - Inverter overload
User reset
A125
Return fan 2 - Heat sink overheat
User reset
A126
Return fan 2 - DC overload
User reset
A127
Return fan 2 - Phase lost
User reset
A128
Return fan 2 - Electric thermal
User reset
A129
Return fan 2 - Parameter save error
User reset
A130
Return fan 2 - HW fault
User reset
A131
Return fan 2 - Communication error
User reset
A132
Return fan 2 - Cooling fan fault
User reset
A133
Return fan 2 - Cut off
User reset
A134
Return fan 2 - External fault A
User reset
A135
Return fan 2 - External fault B
User reset
A136
Return fan 2 - Option
User reset
