VTS Ventus VVS300 Инструкция по инсталляции ПО онлайн [35/47] 676415
![VTS Ventus VVS300 Инструкция по инсталляции ПО онлайн [35/47] 676415](/views2/1894674/page35/bg23.png)
uPC3 – rel 1.8 – 11/2021
35
A183
Return fan 4 - Offline
User reset
A184
Return fan 4 - Alarm
User reset
A185
Rotary VFD - Ground fault
User reset
A186
Rotary VFD - Inverter overheat
User reset
A187
Rotary VFD - Motor overheat
User reset
A188
Rotary VFD - Overload
User reset
A189
Rotary VFD - Phase open
User reset
A190
Rotary VFD - Overvoltage
User reset
A191
Rotary VFD - Low voltage
User reset
A192
Rotary VFD - Overcurrent
User reset
A193
Rotary VFD - Inverter overload
User reset
A194
Rotary VFD - Heat sink overheat
User reset
A195
Rotary VFD - DC overload
User reset
A196
Rotary VFD - Phase lost
User reset
A197
Rotary VFD - Electric thermal
User reset
A198
Rotary VFD - Parameter save error
User reset
A199
Rotary VFD - HW fault
User reset
A200
Rotary VFD - Communication error
User reset
A201
Rotary VFD - Cooling fan fault
User reset
A202
Rotary VFD - Cut off
User reset
A203
Rotary VFD - External fault A
User reset
A204
Rotary VFD - External fault B
User reset
A205
Rotary VFD - Option
User reset
A206
Rotary VFD - Offline
User reset
A207
Rotary VFD - Alarm
User reset
A208
IO Module - c.pCOe - Offline
Auto reset
A209
IO Module - c.pCOe - Configuration error
Auto reset
A210
Supply air pressure - Offline
Auto reset
A211
Return air pressure - Offline
Auto reset
A212
Supply humidity - Offline
Auto reset
A213
Return humidity - Offline
Auto reset
A214
Supply temperature - Probe not working
Auto reset
A215
Cooling device - Alarm
User reset
A216
Antifreeze alarm - By digital input
Auto reset until counter
3
3600
A217
Prototype software
Auto reset
A218
High number of retain - Memory writings
User reset
A219
Error in retain - Memory writings
User reset
A220
Return temperature - Probe not working
Auto reset
A221
External temperature - Probe not working
Auto reset
A222
CO2 air quality - Probe not working
Auto reset
A223
Return recovery temp. - Probe not working
Auto reset
A224
Basic - TH-Tune - Offline
Auto reset
A225
Supply temperature - Out of range
User reset
A226
Supply air flow - Warning
User reset
A227
Return air flow - Warning
User reset
A228
Humidifier - Alarm
User reset
