uPC3 – rel 1.8 – 11/2021
36
A229
Humidifier - Maintenance required
Auto reset
A230
Return fan - Maintenance required
Auto reset
A231
Supply fan - Maintenance required
Auto reset
A232
Reheating coil - Maintenance required
Auto reset
A233
Heat recovery - Maintenance required
Auto reset
A234
Supply filter - Alarm
Auto reset
A235
Return filter - Return filter alarm
Auto reset
A236
Basic - TH-Tune - Clock not working
Auto reset
A237
Basic - TH-Tune - Temperature probe not working
Auto reset
A238
Basic - TH-Tune - Humidity probe not working
Auto reset
A239
BMS offline - BMS offline
Auto reset
A240
Supply diff. pressure - Probe not working
User reset
A241
Return diff. pressure - Probe not working
User reset
A242
Fire alarm - By digital input
User reset
A243
Heating coil - Water temperature probe not working
Auto reset
A244
Preheating coil - Water temperature probe not working
Auto reset
A245
After preheating coil - Water temperature probe not working
Auto reset
A246
Heating device - Alarm
Auto reset until counter
3
3600
A247
Fire alarm - By temperature
User reset
A248
Fan group - Alarm
Auto reset
A249
Antifreeze alarm - Heat back water temperature
Auto reset until counter
3
3600
A250
Antifreeze alarm - Preheat back water temperature
Auto reset until counter
3
3600
A251
Supply fan 5 - Ground fault
User reset
A252
Supply fan 5 - Inverter overheat
User reset
A253
Supply fan 5 - Motor overheat
User reset
A254
Supply fan 5 - Overload
User reset
A255
Supply fan 5 - Phase open
User reset
A256
Supply fan 5 - Overvoltage
User reset
A257
Supply fan 5 - Low voltage
User reset
A258
Supply fan 5 - Overcurrent
User reset
A259
Supply fan 5 - Inverter overload
User reset
A260
Supply fan 5 - Heat sink overheat
User reset
A261
Supply fan 5 - DC overload
User reset
A262
Supply fan 5 - Phase lost
User reset
A263
Supply fan 5 - Electric thermal
User reset
A264
Supply fan 5 - Parameter save error
User reset
A265
Supply fan 5 - HW fault
User reset
A266
Supply fan 5 - Communication error
User reset
A267
Supply fan 5 - Cooling fan fault
User reset
A268
Supply fan 5 - Cut off
User reset
A269
Supply fan 5 - External fault A
User reset
A270
Supply fan 5 - External fault B
User reset
A271
Supply fan 5 - Option
User reset
A272
Supply fan 5 - Offline
User reset
A273
Supply fan 5 - Alarm
User reset
A274
Return fan 5 - Ground fault
User reset
