uPC3 – rel 1.8 – 11/2021
37
A275
Return fan 5 - Inverter overheat
User reset
A276
Return fan 5 - Motor overheat
User reset
A277
Return fan 5 - Overload
User reset
A278
Return fan 5 - Phase open
User reset
A279
Return fan 5 - Overvoltage
User reset
A280
Return fan 5 - Low voltage
User reset
A281
Return fan 5 - Overcurrent
User reset
A282
Return fan 5 - Inverter overload
User reset
A283
Return fan 5 - Heat sink overheat
User reset
A284
Return fan 5 - DC overload
User reset
A285
Return fan 5 - Phase lost
User reset
A286
Return fan 5 - Electric thermal
User reset
A287
Return fan 5 - Parameter save error
User reset
A288
Return fan 5 - HW fault
User reset
A289
Return fan 5 - Communication error
User reset
A290
Return fan 5 - Cooling fan fault
User reset
A291
Return fan 5 - Cut off
User reset
A292
Return fan 5 - External fault A
User reset
A293
Return fan 5 - External fault B
User reset
A294
Return fan 5 - Option
User reset
A295
Return fan 5 - Offline
User reset
A296
Return fan 5 - Alarm
User reset
A297
EC Supply fan 1 - Undervoltage
Auto reset
A298
EC Supply fan 1 - Overvoltage
Auto reset
A299
EC Supply fan 1 - IGBTOvercurrent
User reset
A300
EC Supply fan 1 - Hot
User reset
A301
EC Supply fan 1 - Phase Loss
User reset
A302
EC Supply fan 1 - Parameters CRC
User reset
A303
EC Supply fan 1 - Circuit fault
User reset
A304
EC Supply fan 1 - Motor fault
User reset
A305
EC Supply fan 1 - Too hot
User reset
A306
EC Supply fan 1 - I2R IGBT fault
User reset
A307
EC Supply fan 2 - Undervoltage
Auto reset
A308
EC Supply fan 2 - Overvoltage
Auto reset
A309
EC Supply fan 2 - IGBTOvercurrent
User reset
A310
EC Supply fan 2 - Hot
User reset
A311
EC Supply fan 2 - Phase Loss
User reset
A312
EC Supply fan 2 - Parameters CRC
User reset
A313
EC Supply fan 2 - Circuit fault
User reset
A314
EC Supply fan 2 - Motor fault
User reset
A315
EC Supply fan 2 - Too hot
User reset
A316
EC Supply fan 2 - I2R IGBT fault
User reset
A317
EC Return fan 1 - Undervoltage
Auto reset
A318
EC Return fan 1 - Overvoltage
Auto reset
A319
EC Return fan 1 - IGBTOvercurrent
User reset
A320
EC Return fan 1 - Hot
User reset
