uPC3 – rel 1.8 – 11/2021
43
A551
Supply fan 10 - Low voltage
User reset
A552
Supply fan 10 - Overcurrent
User reset
A553
Supply fan 10 - Inverter overload
User reset
A554
Supply fan 10 - Heat sink overheat
User reset
A555
Supply fan 10 - DC overload
User reset
A556
Supply fan 10 - Phase lost
User reset
A557
Supply fan 10 - Electric thermal
User reset
A558
Supply fan 10 - Parameter save error
User reset
A559
Supply fan 10 - HW fault
User reset
A560
Supply fan 10 - Communication error
User reset
A561
Supply fan 10 - Cooling fan fault
User reset
A562
Supply fan 10 - Cut off
User reset
A563
Supply fan 10 - External fault A
User reset
A564
Supply fan 10 - External fault B
User reset
A565
Supply fan 10 - Option
User reset
A566
Supply fan 10 - Alarm
User reset
A567
Return fan 10 - Ground fault
User reset
A568
Return fan 10 - Inverter overheat
User reset
A569
Return fan 10 - Motor overheat
User reset
A570
Return fan 10 - Overload
User reset
A571
Return fan 10 - Phase open
User reset
A572
Return fan 10 - Overvoltage
User reset
A573
Return fan 10 - Low voltage
User reset
A574
Return fan 10 - Overcurrent
User reset
A575
Return fan 10 - Inverter overload
User reset
A576
Return fan 10 - Heat sink overheat
User reset
A577
Return fan 10 - DC overload
User reset
A578
Return fan 10 - Phase lost
User reset
A579
Return fan 10 - Electric thermal
User reset
A580
Return fan 10 - Parameter save error
User reset
A581
Return fan 10 - HW fault
User reset
A582
Return fan 10 - Communication error
User reset
A583
Return fan 10 - Cooling fan fault
User reset
A584
Return fan 10 - Cut off
User reset
A585
Return fan 10 - External fault A
User reset
A586
Return fan 10 - External fault B
User reset
A587
Return fan 10 - Option
User reset
A588
Return fan 10 - Alarm
User reset
A589
EC Supply fan 3 - Undervoltage
Auto reset
A590
EC Supply fan 3 - Overvoltage
Auto reset
A591
EC Supply fan 3 - IGBTOvercurrent
User reset
A592
EC Supply fan 3 - Hot
User reset
A593
EC Supply fan 3 - Phase Loss
User reset
A594
EC Supply fan 3 - Parameters CRC
User reset
A595
EC Supply fan 3 - Circuit fault
User reset
A596
EC Supply fan 3 - Motor fault
User reset
