uPC3 – rel 1.8 – 11/2021
44
A597
EC Supply fan 3 - Too hot
User reset
A598
EC Supply fan 3 - I2R IGBT fault
User reset
A599
EC Return fan 3 - Undervoltage
Auto reset
A600
EC Return fan 3 - Overvoltage
Auto reset
A601
EC Return fan 3 - IGBTOvercurrent
User reset
A602
EC Return fan 3 - Hot
User reset
A603
EC Return fan 3 - Phase Loss
User reset
A604
EC Return fan 3 - Parameters CRC
User reset
A605
EC Return fan 3 - Circuit fault
User reset
A606
EC Return fan 3 - Motor fault
User reset
A607
EC Return fan 3 - Too hot
User reset
A608
EC Return fan 3 - I2R IGBT fault
User reset
A609
EC Supply fan 4 - Undervoltage
Auto reset
A610
EC Supply fan 4 - Overvoltage
Auto reset
A611
EC Supply fan 4 - IGBTOvercurrent
User reset
A612
EC Supply fan 4 - Hot
User reset
A613
EC Supply fan 4 - Phase Loss
User reset
A614
EC Supply fan 4 - Parameters CRC
User reset
A615
EC Supply fan 4 - Circuit fault
User reset
A616
EC Supply fan 4 - Motor fault
User reset
A617
EC Supply fan 4 - Too hot
User reset
A618
EC Supply fan 4 - I2R IGBT fault
User reset
A619
EC Return fan 4 - Undervoltage
Auto reset
A620
EC Return fan 4 - Overvoltage
Auto reset
A621
EC Return fan 4 - IGBTOvercurrent
User reset
A622
EC Return fan 4 - Hot
User reset
A623
EC Return fan 4 - Phase Loss
User reset
A624
EC Return fan 4 - Parameters CRC
User reset
A625
EC Return fan 4 - Circuit fault
User reset
A626
EC Return fan 4 - Motor fault
User reset
A627
EC Return fan 4 - Too hot
User reset
A628
EC Return fan 4 - I2R IGBT fault
User reset
A629
EC Supply fan 5 - Undervoltage
Auto reset
A630
EC Supply fan 5 - Overvoltage
Auto reset
A631
EC Supply fan 5 - IGBTOvercurrent
User reset
A632
EC Supply fan 5 - Hot
User reset
A633
EC Supply fan 5 - Phase Loss
User reset
A634
EC Supply fan 5 - Parameters CRC
User reset
A635
EC Supply fan 5 - Circuit fault
User reset
A636
EC Supply fan 5 - Motor fault
User reset
A637
EC Supply fan 5 - Too hot
User reset
A638
EC Supply fan 5 - I2R IGBT fault
User reset
A639
EC Return fan 5 - Undervoltage
Auto reset
A640
EC Return fan 5 - Overvoltage
Auto reset
A641
EC Return fan 5 - IGBTOvercurrent
User reset
A642
EC Return fan 5 - Hot
User reset
