uPC3 – rel 1.8 – 11/2021
45
A643
EC Return fan 5 - Phase Loss
User reset
A644
EC Return fan 5 - Parameters CRC
User reset
A645
EC Return fan 5 - Circuit fault
User reset
A646
EC Return fan 5 - Motor fault
User reset
A647
EC Return fan 5 - Too hot
User reset
A648
EC Return fan 5 - I2R IGBT fault
User reset
A649
EC Supply fan 6 - Undervoltage
Auto reset
A650
EC Supply fan 6 - Overvoltage
Auto reset
A651
EC Supply fan 6 - IGBTOvercurrent
User reset
A652
EC Supply fan 6 - Hot
User reset
A653
EC Supply fan 6 - Phase Loss
User reset
A654
EC Supply fan 6 - Parameters CRC
User reset
A655
EC Supply fan 6 - Circuit fault
User reset
A656
EC Supply fan 6 - Motor fault
User reset
A657
EC Supply fan 6 - Too hot
User reset
A658
EC Supply fan 6 - I2R IGBT fault
User reset
A659
EC Return fan 6 - Undervoltage
Auto reset
A660
EC Return fan 6 - Overvoltage
Auto reset
A661
EC Return fan 6 - IGBTOvercurrent
User reset
A662
EC Return fan 6 - Hot
User reset
A663
EC Return fan 6 - Phase Loss
User reset
A664
EC Return fan 6 - Parameters CRC
User reset
A665
EC Return fan 6 - Circuit fault
User reset
A666
EC Return fan 6 - Motor fault
User reset
A667
EC Return fan 6 - Too hot
User reset
A668
EC Return fan 6 - I2R IGBT fault
User reset
A669
EC Supply fan 7 - Undervoltage
Auto reset
A670
EC Supply fan 7 - Overvoltage
Auto reset
A671
EC Supply fan 7 - IGBTOvercurrent
User reset
A672
EC Supply fan 7 - Hot
User reset
A673
EC Supply fan 7 - Phase Loss
User reset
A674
EC Supply fan 7 - Parameters CRC
User reset
A675
EC Supply fan 7 - Circuit fault
User reset
A676
EC Supply fan 7 - Motor fault
User reset
A677
EC Supply fan 7 - Too hot
User reset
A678
EC Supply fan 7 - I2R IGBT fault
User reset
A679
EC Return fan 7 - Undervoltage
Auto reset
A680
EC Return fan 7 - Overvoltage
Auto reset
A681
EC Return fan 7 - IGBTOvercurrent
User reset
A682
EC Return fan 7 - Hot
User reset
A683
EC Return fan 7 - Phase Loss
User reset
A684
EC Return fan 7 - Parameters CRC
User reset
A685
EC Return fan 7 - Circuit fault
User reset
A686
EC Return fan 7 - Motor fault
User reset
A687
EC Return fan 7 - Too hot
User reset
A688
EC Return fan 7 - I2R IGBT fault
User reset
