uPC3 – rel 1.8 – 11/2021
46
A689
EC Supply fan 8 - Undervoltage
Auto reset
A690
EC Supply fan 8 - IGBTOvercurrent
User reset
A691
EC Supply fan 8 - Hot
User reset
A692
EC Supply fan 8 - Phase Loss
User reset
A693
EC Supply fan 8 - Parameters CRC
User reset
A694
EC Supply fan 8 - Circuit fault
User reset
A695
EC Supply fan 8 - Motor fault
User reset
A696
EC Supply fan 8 - Too hot
User reset
A697
EC Supply fan 8 - I2R IGBT fault
User reset
A698
EC Return fan 8 - Undervoltage
Auto reset
A699
EC Return fan 8 - Overvoltage
Auto reset
A700
EC Return fan 8 - IGBTOvercurrent
User reset
A701
EC Return fan 8 - Hot
User reset
A702
EC Return fan 8 - Phase Loss
User reset
A703
EC Return fan 8 - Parameters CRC
User reset
A704
EC Return fan 8 - Circuit fault
User reset
A705
EC Return fan 8 - Motor fault
User reset
A706
EC Return fan 8 - Too hot
User reset
A707
EC Return fan 8 - I2R IGBT fault
User reset
A708
EC Supply fan 9 - Undervoltage
Auto reset
A709
EC Supply fan 9 - Overvoltage
Auto reset
A710
EC Supply fan 9 - IGBTOvercurrent
User reset
A711
EC Supply fan 9 - Hot
User reset
A712
EC Supply fan 9 - Phase Loss
User reset
A713
EC Supply fan 9 - Parameters CRC
User reset
A714
EC Supply fan 9 - Circuit fault
User reset
A715
EC Supply fan 9 - Motor fault
User reset
A716
EC Supply fan 9 - Too hot
User reset
A717
EC Supply fan 9 - I2R IGBT fault
User reset
A718
EC Return fan 9 - Undervoltage
Auto reset
A719
EC Return fan 9 - Overvoltage
Auto reset
A720
EC Return fan 9 - IGBTOvercurrent
User reset
A721
EC Return fan 9 - Hot
User reset
A722
EC Return fan 9 - Phase Loss
User reset
A723
EC Return fan 9 - Parameters CRC
User reset
A724
EC Return fan 9 - Circuit fault
User reset
A725
EC Return fan 9 - Motor fault
User reset
A726
EC Return fan 9 - Too hot
User reset
A727
EC Return fan 9 - I2R IGBT fault
User reset
A728
EC Supply fan 10 - Undervoltage
Auto reset
A729
EC Supply fan 10 - Overvoltage
Auto reset
A730
EC Supply fan 10 - IGBTOvercurrent
User reset
A731
EC Supply fan 10 - Hot
User reset
A732
EC Supply fan 10 - Phase Loss
User reset
A733
EC Supply fan 10 - Parameters CRC
User reset
A734
EC Supply fan 10 - Circuit fault
User reset
