uPC3 – rel 1.8 – 11/2021
47
A735
EC Supply fan 10 - Motor fault
User reset
A736
EC Supply fan 10 - Too hot
User reset
A737
EC Supply fan 10 - I2R IGBT fault
User reset
A738
EC Return fan 10 - Undervoltage
Auto reset
A739
EC Return fan 10 - Overvoltage
Auto reset
A740
EC Return fan 10 - IGBTOvercurrent
User reset
A741
EC Return fan 10 - Hot
User reset
A742
EC Return fan 10 - Phase Loss
User reset
A743
EC Return fan 10 - Parameters CRC
User reset
A744
EC Return fan 10 - Circuit fault
User reset
A745
EC Return fan 10 - Motor fault
User reset
A746
EC Return fan 10 - Too hot
User reset
A747
EC Return fan 10 - I2R IGBT fault
User reset
A748
IO Module - IO PCB - Offline
User reset
A749
DX Reverse - Alarm
Auto reset until counter
3
3600
A750
Filter alarm - high pressure
User reset
A751
RRG alarm - no work confirmation
User reset
A752
cPCOE - Offline
Auto reset
A753
THTune - Alarm temperature
Auto reset
A754
cPCOE - Alarm configuration
Auto reset
A755
THTune - Alarm humidity
Auto reset
A756
THTune - Alarm clock
Auto reset
A757
Supply air pressure - Filter - Offline
Auto reset
A758
Supply air pressure - Filter 2 - Offline
Auto reset
A759
Return air pressure - Filter - Offline
Auto reset
A760
Supply diff. pressure - Filter - Probe not working
User reset
A761
Supply diff. pressure - Filter 2 - Probe not working
User reset
A762
Return diff. pressure - Probe not working
User reset
A763
Supply filter Modbus - Alarm
Auto reset
A764
Supply filter 2 Modbus - Alarm
Auto reset
A765
Return filter Modbus - Alarm
Auto reset
