Hitachi DS 14 DFL [10/90] English

English

(2) Regarding the temperatures of the rechargeable

battery

The temperatures for rechargeable batteries are as

shown in Table 2, and batteries that have become

hot should be cooled for a while before being

recharged.

Table 2 Recharging ranges of batteries

(3) Regarding recharging time

Depending on the combination of the charger and

batteries, the charging time will become as shown

in Table 3.

Table 3 Charging time (At 20°C)

NOTE

The charging time may vary according to

temperature and power source voltage.

4. Disconnect the charger’s power cord from the

receptacle

5. Hold the charger firmly and pull out the battery

NOTE

After charging, pull out batteries from the charger

first, and then keep the batteries properly.

How to make the batteries perform longer.

(1) Recharge the batteries before they become

completely exhausted.

When you feel that the power of the tool becomes

weaker, stop using the tool and recharge its battery.

If you continue to use the tool and exhaust the

electric current, the battery may be damaged and

its life will become shorter.

(2) Avoid recharging at high temperatures.

A rechargeable battery will be hot immediately after

use. If such a battery is recharged immediately after

use, its internal chemical substance will deteriorate,

and the battery life will be shortened. Leave the

battery and recharge it after it has cooled for a while.

CAUTION

䡬 When the battery charger has been continuosly

used, the battery charger will be heated, thus con-

CHARGING

Before using the driver drill, charge the battery as

follows.

1. Connect the charger’s power cord to the receptacle.

When connecting the plug of the charger to a

receptacle, the charge status lamp will blink in red.

(At 1-second intervals).

2. Insert the battery into the charger.

Firmly insert the battery into the charger till it

contacts the bottom of the charger and checking

the polarities as shown in Fig. 3.

CAUTION:

䡬 If the batteries are inserted in the reverse direction,

not only recharging will become impossible, but it

may also cause problems in the charger such as

a deformed recharging terminal.

3. Charging

When inserting a battery in the charger, the charge

status lamp will light up continuously in red.

When the battery becomes fully recharged, the

charge status lamp will blink in red. (At 1-second

intervals.) (See Table 1)

(1) Lamp indication

The indications of the lamp will be as shown in

Table 1, according to the condition of the charger

or the rechargeable battery.

Table 1

Indications of the lamp

Before Blinks Lights for 0.5 seconds. Does not light

charging for 0.5 seconds. (off for 0.5 seconds)

Lights Lights continuously

Blinks Lights for 0.5 seconds. Does not light

for 0.5 seconds. (off for 0.5 seconds)

Flickers Lights for 0.1 seconds. Does not light

for 0.1 seconds. (off for 0.1 seconds)

■■■■■■■■■■■■■

Lights Lights continuously

Overheat

standby

Overheat

lamp

(green)

While

charging

Charging

complete

Charging

impossible

Battery overheated.

Unable to charge.

(Charging will

commence when

battery cools)

Charge

status lamp

(red)

Malfunction in the

battery or the charger

Temperatures at which the

Rechargeable batteries

battery can be recharged

BCL1415, BCL1430, EBL1430,

BCL1815, EBM1830

0°C – 50°C

NOTE: When standby for cooling battery, UC18YRL cools the overheated battery by cooling fan.

Charger

UC18YGL UC18YRL

Battery

BCL1415, BCL1815 Approx.

30 min.

Approx.

20 min.

BCL1430, EBL1430,

Approx.

65 min.

Approx.

45 min.

EBM1830
