stituting the cause of the failures. Once the charging

has been completed, give 15 minutes rest until the

next charging.

䡬 If the battery is recharged when it is warm due to

battery use or exposure to sunlight, the pilot lamp

map light in green.

The battery will not be recharged. In such a case,

let the battery cool before charging.

䡬 When the pilot lamp flickers in red (at 0.2-second

intervals), check for and take out any foreign objects

in the charger’s battery installation hole. If there are

no foreign objects, it is probable that the battery

or charger is malfunctioning. Take it to your

authorized Service Center.

PRIOR TO OPERATION

1. Setting up and checking the work environment

Check if the work environment is suitable by

following the precautions.

HOW TO USE

1. Confirm the clutch dial position (See Fig. 4)

The tightening torque of this unit can be adjusted

according to the clutch dial position, at which the

clutch dial is set.

(1) When using this unit as a screwdriver, line up the

one of the numbers “1, 3, 5 ... 22” on the clutch dial,

or the dots, with the triangle mark on the outer body.

(2) When using this unit as a drill, align the clutch dial

drill mark “

” with the triangle mark on the outer

body.

CAUTION

䡬 The clutch dial cannot be set between the numerals

“1, 3, 5 ... 22” or the dots.

䡬 Do not use with the clutch dial numeral between

“22” and the line at the middle of the drill mark.

Doing so may cause damage (See Fig. 5).

2. Tightening torque adjustment

(1) Tightening torque

Tightening torque should correspond in its intensity

to the screw diameter. When too strong torque is

used, the screw head may be broken or be injured.

Be sure to adjust the clutch dial position according

to the screw diameter.

(2) Tightening torque indication

The tightening torque differs depending on the type

of screw and the material being tightened.

The unit indicates the tightening torque with the

numbers “1, 3, 5 ... 22” on the clutch dial, and a

dots. The tightening toque at position “1” is the

weakest and the torque is strongest at the highest

number (See Fig. 4).

(3) Adjusting the tightening torque

Rotate the clutch dial and line up the numbers “1,

3, 5 ... 22” on the clutch dial, or the dots, with the

triangle mark on the outer body. Adjust the clutch

dial in the weak or the strong torque direction

according to the torque you need.

CAUTION

䡬 The motor rotation may be locked to cease while

the unit is used as drill. While operating the driver

drill, take care not to lock the motor.

䡬 Too long hammering may cause the screw broken

due to excessive tightening.

3. Change rotation speed

Operate the shift knob to change the rotational

speed. Move the shift knob in the direction of the

arrow (See Figs. 6 and 7).

When the shift knob is set to “LOW”, the drill

rotates at a low speed. When set to “HIGH”, the

drill rotates at a high speed.

CAUTION

䡬 When changing the rotational speed with the shift

knob, confirm that the switch is off.

Changing the speed while the motor is rotating will

damage the gears.

䡬 When setting the shift knob to “HIGH” (high speed)

and the position of the clutch dial is “17” or “22”,

it may happen that the clutch does not engaged

and that the motor is locked. In such a case, please

set the shift knob to “LOW” (low speed).

䡬 If the motor is locked, immediately turn the power

off. If the motor is locked for a while, the motor

or battery may be burnt.

䡬 To extend the lifetime, the lithium-ion battery equips

with the protection function to stop the output.

Therefore, if the tool is overloaded, the motor may

stop. However, this is not the trouble but the result

of protection function. In this case, release the switch

of tool and eliminate the causes of overloading.

4. The scope and suggestions for uses

The usable scope for various types of work based

on the mechanical structure of this unit is shown

in Table 4.

Work Suggestions

Wood

Drilling Steel Use for drilling purpose.

Aluminum

Machine screw Use the bit or socket matching the screw diameter.

Driving

Wood screw Use after drilling a pilot hole.

Table 4
