Hitachi DS 14 DFL [12/90] English

English

5. How to select tightening torque and rotational speed

Table 5

Use

Clutch Dial

Rotating speed selection (Position of the shift knob)

Position

LOW (Low speed) HIGH (High speed)

Machine screw 1 – 22

For 4 mm or smaller diameter

screws.

Driving

Wood screw 1 –

For 6 mm or smaller nominal

diameter screws. (DS18DFL)

For 6 mm or smaller nominal

diameter screws. (DS14DFL)

Wood

For 38 mm or smaller

diameters. (DS18DFL)

Drilling

For 30 mm or smaller

diameters. (DS14DFL)

Metal

For drilling with a metal

working drill bit.

For 6 mm or smaller

diameter screws.

For 4.8 mm or smaller

nominal diameter screws.

(DS18DFL)

For 3.8 mm or smaller

nominal diameter screws.

(DS14DFL)

For 24 mm or smaller

diameters. (DS18DFL)

For 12 mm or smaller

diameters. (DS14DFL)

CAUTION

䡬 The selection examples shown in Table 5 should

be considered as general standard. As different

types of tightening screws and different materials

to be tightened are used in actual works proper

adjustments are naturally necessary.

䡬 When using the driver drill with a machine screw

at HIGH (high speed), a screw may damage or a

bit may loose due to the tightning torque is too

strong. Use the driver drill at LOW (low speed)

when using a machine screw.

NOTE:

The use of the battery BCL1430, EBL1430, EBM1430

and EBM1830 in a cold condition (below 0 degree

Centigrade) can sometimes result in the weakened

tightening torque and reduced amount of work.

This, however, is a temporary phenomenon, and

returns to normal when the battery warms up.

6. Mounting and dismounting of the bit

(1) After inserting a driver bit, etc. into the keyless drill

chuck, firmly grasp the ring and tighten the sleeve

by turning it toward the right (in the clockwise

direction as viewed from the front) (See Fig. 8).

䡬 If the sleeve becomes loose during operation, tighten

it further. The tightening force becomes stronger

when the sleeve is tightened additionally.

(2) Dismounting the bit

Firmly grasp the ring and loosen the sleeve by

turning it toward the left (in the counter-clockwise

direction as viewed from the front) (See Fig. 8).

CAUTION

䡬 When it is no longer possible to loosen the sleeve,

use a vise or similar instrument to secure the bit. Set

the clutch mode between 1 and 11, and then turn

the sleeve to the loose side (left side) while operating

the clutch. It should be easy now to loosen the sleeve.

7. Confirm that the battery is mounted correctly

8. Check the rotational direction

The bit rotates clockwise (viewed from the rear

side) by pushing the R-side of the selector button.

The L-side of the selector button is pushed to turn

the bit counterclockwise (See Fig. 9) (The

and

marks are provided on the body).

9. Switch operation

䡬 When the trigger switch is depressed, the tool

rotates. When the trigger is released, the tool stops.

䡬 The rotational speed of the drill can be controlled by

varying the amount that the trigger switch is pulled.

Speed is low when the trigger switch is pulled slightly

and increases as the trigger switch is pulled more.

NOTE

䡬 A buzzing noise is produced when the motor is about

to rotate; This is only a noise, not a machine failure.

10. Using the hook

CAUTION

䡬 When using the hook, pay sufficient attention so

that the main equipment does not fall. If the tool

falls, there is a risk of accident.

䡬 Do not attach the tip tool except phillips bit to the

tool main unit when carrying the tool main unit with

the hook suspended from a waist belt.

Injury may result if you carry the equipment

suspended from the waist belt with sharp tipped

components such as drill bit attached.

The hook can be installed on the right or left side and

the angle can be adjusted in 5 steps between 0° and

80°.

(1) Operating the hook

(a) Pull out the hook toward you in the direction

of arrow (A) and turn in the direction of arrow

(B) (Fig. 10).

(b) The angle can be adjusted in 5 steps (0°, 20°,

40°, 60°, 80°).

Adjust the angle of the hook to the desired

position for use.

(2) Switching the hook position
