Skil 4581 LA [11/116] Environment

- 4 settings for fast cutting in dierent materials, straight

cuts only

1 = metal

2 = plastic

3 = hard wood

4 = soft wood

! always select “0” when sawing splinter-sensitive

material

• Dust suction !a

! do not use vacuum cleaner when cutting metal

• Dust blowing !b

• Saw blade storage @

! for T-shank blades only

• Spot light #

• Operating the tool

- before switching on the tool, ensure that front end of

footplate rests at on the workpiece

- hold tool rmly with both hands, so you will have full

control of the tool at all times

! while working, always hold the tool at the

grey-coloured grip area(s) $

- ensure that complete surface of footplate rests rmly

on the workpiece

! ensure that the blade has come to a complete

standstill, before you lift the tool from the

workpiece

- keep ventilation slots J 2 uncovered

APPLICATION ADVICE

• Use the appropriate saw blades %

! tool accepts most commonly available T-shank

and U-shank blades ^

• When cutting metals, lubricate saw blade regularly with

oil

• Pre-drill a hole before making cut-outs &

• Splinter-free cutting

- cover cutting-line with several layers of wide tape

before cutting

- always face the good side of the workpiece down

• For more tips see www.skil.com

MAINTENANCE / SERVICE

• This tool is not intended for professional use

• Always keep tool and cord clean (especially ventilation

slots J 2)

! disconnect the plug before cleaning

• If the tool should fail despite the care taken in

manufacturing and testing procedures, repair should be

carried out by an after-sales service centre for SKIL

power tools

- send the tool undismantled together with proof of

purchase to your dealer or the nearest SKIL service

station (addresses as well as the service diagram of

the tool are listed on www.skil.com)

ENVIRONMENT

• Do not dispose of electric tools, accessories and

packaging together with household waste material

(only for EU countries)

- in observance of European Directive 2002/96/EC on

waste of electric and electronic equipment and its

implementation in accordance with national law,

electric tools that have reached the end of their life

must be collected separately and returned to an

environmentally compatible recycling facility

- symbol * will remind you of this when the need for

disposing occurs

DECLARATION OF CONFORMITY

• We declare under our sole responsibility that the product

described under “Technical data” is in conformity with the

following standards or standardization documents: EN

60745, EN 61000, EN 55014, in accordance with the

provisions of the directives 2004/108/EC, 2006/42/EC,

2011/65/EU, 2009/125/EC (EU regulation 1194/2012)

• Technical file at: SKIL Europe BV (PT-SEU/ENG1),

4825 BD Breda, NL

¹ÊÁÂÆÎ¹Æ¼½ÊÇÇ¾¼½Æ

È½Ê¹ÌÁÇÆËŵÆ¿ÁÆ½½ÊÁÆ¿

ÍÊÇÈ½Ɠˁ˅ʿ˂Ê½¼¹Ɠ

Ä¹¾ÁÂÃ¿Ê¹¹¾

ÈÈÊÇÎ¹Ä¹Æ¹¿½Ê

09.12.2013

NOISE/VIBRATION

• Measured in accordance with EN 60745 the sound

pressure level of this tool is 89 dB(A) and the sound

power level 100 dB(A) (standard deviation: 3 dB), and the

vibration ✱ (hand-arm method; uncertainty K = 1.5 m/s²)

✱ when cutting wood 12.7 m/s²

✱ when cutting metal 9. 2 m/s²

• The vibration emission level has been measured in

accordance with a standardised test given in EN 60745; it

may be used to compare one tool with another and as a

preliminary assessment of exposure to vibration when

using the tool for the applications mentioned

- using the tool for dierent applications, or with dierent

or poorly maintained accessories, may signicantly

increase the exposure level

- the times when the tool is switched o or when it is

running but not actually doing the job, may signicantly

reduce the exposure level

! protect yourself against the effects of vibration

by maintaining the tool and its accessories,

keeping your hands warm, and organizing your

work patterns



Scie sauteuse 4581

INTRODUCTION

• Cet outil est conçu pour eectuer des découpes et

coupes dans le bois, les matières plastiques, le métal, les

plaques en céramique et le caoutchouc, et est approprié
