Secure Device Server User Manual
94
SN3401 / SN3401P / SN3402 / SN3402P
SN3401 SN3402 SN3401P SN3402P
Connectors
Serial 1 x DB-9 Male 2 x DB-9 Male 1 x DB-9 Male 2 x DB-9 Male
Network 1 x RJ-45 Female
Power
1 x DC Jack
1 x 3-pole Terminal Block
1 x DC Jack
1 x 3-pole Terminal Block
1 x RJ-45 (PoE, IEEE 802.3af)
Switches
Reset 1 x semi-recessed pushbutton
LEDs
Power 1 (Green)
Status 1 (Yellow Green / Red)
10/100 Mbps 2 (Green / Orange)
Ports
1
(Green / Orange)
2
(Green / Orange)
1
(Green / Orange)
2
(Green / Orange)
Input Voltage
DC Jack
9 V DC (Power Adapter: 9 V DC
100-240 V AC 50~60 Hz)
DC Jack: 9 V DC
Note: Power adapter is not included in
the package, but is available for
purchase.
Terminal
Block
9-48 V DC 9-48 V DC
PoE N/A 48 V DC
Power Consumption
DC
9V:1.18W:6BTU
48V:1.30W:6BTU
9V:1.19W:6BTU
48V:1.30W:6BTU
DC 9V:1.18W:6BTU
DC 48V:1.30W:6BTU
DC 9V:1.19W:6BTU
DC48V:1.30W:6BTU
PoE N/A N/A 1.475W: 7BTU 1.48V: 7BTU
Interfaces
