Aten SN3002 [56/111] Syslog

Secure Device Server User Manual

Syslog

Item Description

Enable Syslog service Check to enable Syslog service for sending event notifications

to a Syslog server, as specified by the Advanced tab (see

page 45).

Server Address / Port Enter the Syslog server’s address and port value.
