Appendix
95
Serial
RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422: Tx+, Tx-, Rx+, Rx-, GND
RS-485 (4-wire): Tx+, Tx-, Rx+, Rx-, GND
RS-485 (2-wire): Data+, Data-, GND
Pull High/Low Resistor for RS-485: 1 kilo-ohm, 150 kilo-ohms
Baud Rate: 110, 134, 150, 300, 600, 1200, 1800, 2400, 4800, 7200,
9600, 19200, 38400, 57600, 115200, 230400, 460800, 921600 bps
Data Bits: 5, 6, 7, 8
Parity: None, Even, Odd, Space, Mark
Stop Bits: 1, 1.5, 2
Flow Control: RTS/CTS, DTR/DSR, XON/XOFF
Network 10 / 100 Base TX; Built-in 1.5 kV Magnetic Isolation Protection
Industrial
Protocols
Ethernet: Modbus TCP Client (Master), Modbus TCP Server (Slave)
Serial: Modbus RTU/ASCII Master, Modbus RTU/ASCII Slave
Max. 16 connections under Modbus Master mode and 32 connections
under Modbus Slave mode.
Compliance
EMC: EN 55032/35
EMI: CISPR 32, FCC Part 15B Class A
EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 2 kV (Power Adapter), 1kV (Terminal
Block); Signal: 1 kV
IEC 61000-4-6 CS: 150 kHz to 10 MHz: 3 V/m; 10 kHz to 30 MHz: 3 to 1
V/m; 30 kHz to 80 MHz: 1 V/m
IEC 61000-4-8 PFMF
IEC 61000-4-11 DIPs
Safety: UL 60950-1 and UL 62368-1 standards compliant
RoHS
Environmental
Operating
Temperature
0 – 60 °C
Storage
Temperature
-40 – 75 °C
Humidity 5 – 95% RH, Non-condensing
Physical Properties
Housing Metal
Weight 0.20 kg 0.21 kg 0.21 kg 0.22 kg
SN3401 SN3402 SN3401P SN3402P
