Chapter 9. Virtual Serial Port Manager

Menu and Toolbar

The Virtual Serial Port Manager menu and toolbar consist of the same

functions. Users can either click the menu items or buttons to invoke the

desired function, as described in the table below.

Target Information

The Target Information fields allow users to install (map) ports on an offline

target device, as described below.

Item Action

Enum Targets This function searches and lists all SN devices within the LAN

— these include Secure Device Server, as well as ATEN

Serial Console Servers. The results are shown in the Target

List panel (see Target List, page 82, for details). Beware that

all devices listed in the Target List will be deleted when the

delete function is invoked. Be sure to remove any devices

from the list that you don’t want to delete before invoking the

delete function.

Enum Ports This function lists the existing ports for the target device

currently selected in the Target List. The results are shown in

the Port List panel.

Map After selecting a port from the Port List panel, selecting this

function maps the device’s COM port to a virtual COM port on

the user’s PC.

Unmap After selecting a port from the Mapped Ports list, selecting this

function removes the mapping between the PC and the

device’s COM port.

Field Action

Target IP Address Input the IP address of the target that you want to map COM

ports to.

Base Socket Port The base socket port of the target device. For Real COM port

operation, the default base socket port is 5200.

Target Name The name of the target. If it is different from the target’s real

name, will be replaced by the real one. Note that the name is

not related to the mapping / unmapping process. Only the IP

address, socket port and target type are relevant.

Target Type The type of target to be mapped. SN3001 / SN3002 and ATEN

Serial Console Servers are valid target types.

Note: SN3001 includes SN3001P, and SN3002 includes

SN3002P.

Add Target Creates an entry in the Target List based on the above

information.

Delete Target Remove the currently selected target from the Target List.
