Aten SN3002 [64/111] User accounts

Secure Device Server User Manual

User Accounts

The User Accounts submenu consists of User and Authentication Services

pages, which allow users to add/edit login accounts or utilize third-party

authentication services for managing the user accounts of the Secure Device

Server, respectively.

For details on configuring user accounts and third-party authentication

services, see Chapter 5, User Management.
