Secure Device Server User Manual
40
Click Save for the changes to take effect.
Login session timeout
(0 ~ 180 min)
Automatically logs out user(s) when there are no actions done
on the Secure Device Server’s web interface for the amount of
time set. “0” means the user will never be automatically logged
out.
Reboot System Reboots the Secure Device Server.
Service ports Sets the service port values for the following:
HTTP: used for browser access (default = 80)
HTTPS: used for secure browser access (default = 443)
SSH: used for SSH access (default = 22)
Telnet: used for Telnet access. (default = 23)
Base socket: used for receiving and accepting TCP
connections (default = 5001). For example, when the
base socket value is 5001, the device’s TCP port value
for Port 1/2 via Telnet and SSH will be 5001/5002 and
5101/5102, respectively.
Note:
1. Valid entries for all service ports are from 1 – 65535.
2. A system restart is required when any of the service
port settings have been changed.
IP Installer
Configuration
Select to determine if the IP Installer utility can detect for and/
or change the Secure Device Server‘s IP address.
Enabled: IP Installer can detect for and change the
unit’s IP address.
View Only: IP Installer can only detect for but unable to
change the unit’s IP address.
Disabled: IP Installer cannot detect for and change the
unit’s IP address.
Item Description
