Chapter 9. Virtual Serial Port Manager

Port Unmapping

To unmap a virtual COM port, do the following:

1. Select the mapped COM port (in the far-right panel) to bring up the Port

Unmapping dialog box:

Note: If the dialog box doesn’t come up, either click Unmap… on the

button bar, or select Unmap… from the menu.

2. Click OK to complete the operation.
