crucial flight data for each flights.

2.2 Flight Mode

Three flight modes are available. The details of each flight mode is listed in the table below:

Flight

Mode

GPS Availability

Remark

GPS

GPS enabled

GPS mode works best when GPS modules is enabled and more than 6 GPS

satellites are available. Under GPS mode, there are three different

statuses:

P-GPS: Both GPS and Optical Flow signal are optimal, using both GPS and

Optical flow to implement hovering.

P-OPTI: Optical Flow sensor signal is optimal but GPS signal is not optimal,

using only Optical flow to implement hovering.

P-ATTI: Neither GPS or Optical Flow Sensor signal is optimal, using only

barometer to stabilize aircraft’s attitude.

The aircraft automatically switch between the status depending on signal

of the GPS and Optical Flow sensor.

ATTI

GPS disabled

ATTI mode works when GPS is disabled and uses only barometer to

stabilize the aircraft. Noted that Home Point is not recorded in this mode

and aircraft automatically return home when signal is lost.

GPS enabled

F mode works when more than GPS satellite are available. Intelligent

Orientation Control (IOC) is activated in this mode. User may use IOC to

lock the orientation of the aircraft. For more information about the IOC,

refer to “IOC”.

2.3 Flight Limits

Flight limits such as height and distance is imposed on the Ncore flight controllers. The details of these flight limites

are described in the following section.

All unmanned aerial vehicle (UAV) operators should abide by all regulations from such organizations as the ICAO

(International Civil Aviation Organization) and their own national airspace regulations. For safety reasons, the flight

limits function is enabled by default to help users use this product safely and legally. The flight limits function includes

height, distance limits and No Fly Zones.
