(3) Mechanical structure of the Phantom has changed, i.e. changed mounting position of the compass.

(4) Severe drifting occurs in flight, i.e. Phantom does not fly in straight lines.

Starting/Stopping the Motors

Starting Motors

A Combination Stick Command (CSC) is used to start the motors instead of simply pushing the stick up. Push both

sticks to their bottom corners to start the motors. Once the motors have spun up, release both sticks

simultaneously.

Stopping Motors

There are two methods to stop the motors.

Method 1: When the Phantom has landed, push the throttle down, then conduct CSC. Motors will stop immediately.

Release both sticks once motors stop.

Method 2: When the aircraft has landed, push the throttle down and hold. Motors will stop after 3 seconds.

Do not execute CSC during normal flight. This will stop the motors and cause the aircraft to drop without control.

Conduct the CSC as neatly as you can. Release the sticks once motors start/stop.

Pull down the throttle stick to descend. The stick will lock into place and the aircraft will descend steadily. Push the throttle

stick upward to release throttle lock.

6.4 Flight Test

Take off/Landing Procedures

(1) Place the aircraft on open flat ground with battery indicators facing towards you.

(2) Power on the remote controller and mobile device, then the Smart Flight Battery.

(3) Launch the DJI Pilot App and start link it with your mobile device then enter the Camera page.

(4) Wait until the Aircraft Indicator blinks purple. This means the Home Point is recorded and it is safe to fly now. If

it flashes yellow, it means no Home Point is recorded, user should not take off the aircraft.

(5) Push the throttle up slowly to take off.

(6) Shoot photos and videos using the DJI Pilot App.

(7) To land, hover over a level surface and gently pull down on the throttle gently to descend.

(8) After landing, execute the CSC command or hold the throttle at its lowest position for 3 seconds or more until

the motors stop.

(9) Turn off the Smart Battery follow by the Remote Controller.
