DJI Inspire 1 Remote Controller [29/63] Charging the smart battery

DJI Inspire 1 Remote Controller [29/63] Charging the smart battery
©2014 DJI All Rights Reserved 29 |
37.5%~50%
25%~37.5%
12.5%~25%
0%~12.5%
<0%
Battery Life
The battery life indicates how many more times the battery can be discharged and recharged before it must be
replaced. When the battery is powered off, press and hold the Circular Power Button for 5 seconds to check the
battery life. The Battery Level Indicators will light up and/or blink as described below for 2 seconds:
Battery Life
LED1
LED2
LED3
LED4
Battery Life
90%~100%
80%~90%
70%~80%
60%~70%
50%~60%
40%~50%
30%~40%
20%~30%
20%
When battery life reaches 0%, it can no longer be used.
For more information about the battery, launch DJI Inspire 1 App and check the information under the
battery tab.
Charging the Smart Battery
1. Connect Battery Charger to a power source (100-240V 50/60Hz).
2. Open the Protection Cap and connect the Smart Battery to the Battery Charger. If the battery level is
above 75%, turn on the battery before charging.
3. The Battery Level Indicator will display the current battery level during charging.
4. The Smart Battery is fully charged when Battery Level Indicators are all off.
5. Air cool the Smart Battery after each flight. Allow the Smart Battery’s temperature to drops to the room
temperature before storing it for an extended period.
