DJI Inspire 1 Remote Controller [58/63] Battery
![DJI Inspire 1 Remote Controller [58/63] Battery](/views2/2003190/page58/bg3a.png)
©2014 DJI All Rights Reserved 58 |
Pan： ±330°
Max Controllable Speed
Pitch： 120°/s
Pan： 180°/s
Battery
Model (Standard)
TB47
Voltage
22.2V
Energy
99.9Wh
Net Weight
570g
Charger (Standard)
Output Power
100W
Charging Time
85min for 4500mAh
Camera
Operating Temperature
0℃ to 40℃
Resolution
1240M
FOV （Field of View）
94°
CMOS
1/2.3”
Lens
F/2.8（21mm equivalent）
Anti-distortion filter
Shooting Mode
Single shoot
Burst shoot（BURST：3/5/7 frames per second，AEB：3/5 frames per
second，0.7EV Bias）
Time lapsed
HD Recording Mode
UHD：4096x2160p24/25，3840x2160p24/25/30
FHD：1920x1080p24/25/30/48/50/60
HD：1280x720p24/25/30/48/50/60
Supported File Format
FAT32/exFAT
Photo format：JPEG，DNG
Video format：MP4/MOV（MPEG-4 AVC/H.264）
Support SD Card Types
SD/SDHC/SDXC Micro SD
Remote Controller
Operating Frequency
5.728 GHz~5.08 GHz (Remote Controller to Remote Controller)
2.420GHz~2.483GHz (Remote Controller to Aircraft)
Transmitting Distance（outdoor and
unobstructed）
2km or above
Receiver（1%PER）
-93dBm
EIRP
10dBm@900M， 8dBm @5.8G，20dBm@2.4G
