©2014 DJI All Rights Reserved 28 |
provided to the aircraft’s to the main controller.
Refer to disclaimer and battery warnings before use. Users take full responsibility for all operations
and usage.
Using Battery
Figure 6
Powering On/Off
Powering on: Press the Power Button once, then press again and hold for 2 seconds to power on. The Power LED will
turn red and the Battery Level Indicators will display the current battery level.
Checking the Battery Level
The Battery Level Indicators display how much remaining power the battery has. When the battery is powered off,
press the Power Button once. The Battery Level Indicators will light up to display the current battery level. See below
for details.
The Battery Level Indicators will also show the current battery level during charging and discharging. The
indicators are defined below.
：LED is on. ：LED is flashing.
：LED is off.
Battery Level
LED1
LED2
LED3
LED4
Battery Level
87.5%~100%
75%~87.5%
62.5%~75%
50%~62.5%
