DJI Inspire 1 Remote Controller [32/63] Remote control
![DJI Inspire 1 Remote Controller [32/63] Remote control](/views2/2003190/page32/bg20.png)
©2014 DJI All Rights Reserved 32 |
3 Remote Control
3.1 Remote Controller Profile
The Inspire 1 remote control is a multi-function wireless communication device that integrates the video downlink
ground system and aircraft remote control system. The video downlink and aircraft remote control system operate at
2.4 GHz The remote control features a number of camera functions, such as taking and previewing photos and video
and controlling gimbal motions. The remote control is powered by 2S rechargeable battery. The current battery level
is displayed by LEDs on the front panel of the remote control.
Compliance Version: The remote control is compliant with both CE and FCC regulations.
Operating Mode: Control can be set to Mode 1 , Mode 2, or Mode 3
Mode 1 ：The right stick serves as the throttle.
Mode 2：The left stick serves as the throttle.
Mode 3：The right stick serves as the throttle and roll control.
Power on the remote control before powering on the aircraft. Then power off the landed aircraft before
powering off the remote control.
3.2 Remote Controller Operations
Powering on and off the Remote Controller
The Inspire 1 remote controller is powered by a 2S rechargeable battery with a capacity of 6000mHA. The battery
level is indicated by the Battery Level LEDs on the front panel. Follow the steps below to power on your remote
controller:
1. When powered off, press the Power Button once and the Battery Level LEDs will display the current battery
level.
2. Then, press and hold the Power Button to power on the remote controller.
3. The remote control will beep when it powers on. The Status LED will blink green rapidly, indicating that the
remote controller and receiver are linking. The Status LED will show a solid green light when linking is
completed.
4. Repeat step 2 to power off the remote controller after finish using it.
