©2014 DJI All Rights Reserved 23 |
Low battery
level warning
The battery
power is low.
Please land the
aircraft.
Aircraft status
indicator blinks
RED slowly.
Tap “Go-home” to have the
aircraft return to the Home
point and land automatically,
or “Cancel”± to resume
normal flight. If no action is
taken, the aircraft will
automatically go home and
land after 10 seconds. Remote
controller will sound an alarm.
Fly the aircraft back and
land it as soon as possible,
then stop the motors and
replace the battery.
Critical Low
battery level
warning
The aircraft must
land immediately.
Aircraft status
indicator blinks
RED quickly.
The DJI Pilot App screen will
flash red and aircraft starts to
descend. Remote controller
will sound an alarm.
The aircraft will begin to
descend and land
automatically.
Estimated
remaining flight
time
Estimated
remaining flight
based on current
battery level.
N/A
N/A
N/A
Color zones on the battery level indicator reflect estimated
remaining flight time and are adjusted automatically, according to the aircraft’s current status.
When the critical battery level warning activates and the aircraft is descending to land automatically, you may
push the throttle upward to hover the aircraft and navigate it to a more appropriate location for landing.
When these warnings are triggered, please bring the aircraft back to the Home point or land to avoid losing
power during flight.
2.7 Dynamic Home Point
Dynamic home point is useful in situations when you are in motion and require a Home point that is different from the
takeoff point. Dynamic home point is only available to the GPS-enabled mobile device. Turn on GPS and data service
to obtain higher accuracy of the mobile device position. The Home point will be reset to position of the mobile device
