©2014 DJI All Rights Reserved 34 |
[1] Camera Settings Dial
Turn the dial to quickly adjust camera settings such as ISO, shutter speed, and aperture without letting go of the
remote control. Move the dial button to left or right to select your preferred settings.
[2] Playback Button
Press to view the images or videos that have already been captured
[3] Shutter Button
Press to take a photo. If burst mode is activated, multiple photos will be taken with a single press.
[4] Recoding button
Press once to start recording video, then press again to stop recording.
Controlling Aircraft
This section explains how to use the various features of the remote controller.
The Remote Control is set to Mode 2 by default.
Stick Neutral/ mid point: Control sticks of the Remote Control are placed at the central position.
