©2014 DJI All Rights Reserved 43 |
Figure 16
The Inspire 1 comes with a 4GB micro-SD card and supports up to a 2TB micro-SD card. A UHS-1 type micro-SD card
is recommended, because the fast read and write capability of these cards enables you to store high-resolution video
data.
Do not remove micro-SD card from the Inspire 1 when it is powered on.
4.1.3 Camera Data Port
Power on the Inspire 1 and then connect a USB cable to the Camera Data Port to download photos or videos from
the camera to your computer.
Figure 17
Power on the aircraft before attempting to download the files.
4.2
4.2.1 3-Axis Gimbal
The 3-axis Gimbal provides a steady platform for the attached camera, allowing you to capture stabilized images and
video from the air. The Gimbal can tilt the camera up to 90 degrees and rotate it up to 330 degrees. Both pitch and
yaw movement can be controlled via the included remote controller (refer to the Remote Controller section for more
