![Yamaha PSR-330 [32/90] Fngrngmd](/views2/2009448/page32/bg20.png)
30
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
QQQQQQQQQQQQQQQQ
QQQQQQQQQQQQQQQQ
¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢
Auto Accompaniment
● F1: The FINGERED 1 Mode
The Fingered 1 mode lets you finger your own chords on the AUTO ACCOMPA-
NIMENT section of the keyboard (i.e. all keys to the left of and including the split-
point key — normally 54) while the PSR-330 supplies appropriately orchestrated
rhythm, bass, and chord accompaniment in the selected style.
The FINGERED 1 mode recognizes the following chords:
F1
FngrngMd
• Notes in parentheses
can be omitted.
• If you play any three
adjacent keys (includ-
ing black keys), the
chord sound will be
cancelled and only
the rhythm instru-
ments will continue
playing (CHORD
CANCEL function).
• An octave produces
accompaniment
based only on the
root.
• A perfect fifth (1 + 5)
produces accompani-
ment based only on
the root and fifth
which can be used
with both major and
minor chords.
• The chord fingerings
listed are all in “root”
position, but other in-
versions can be used
— with the following
exceptions:
m7, m7
b
5, 6, m6,
sus4, aug, dim7,
7
b
5, 6(9), m7_11,
1+2+5.
• Inversion of the
7sus4, 7
#
11 chord are
not recognized if the
5th is omitted.
Chord Name/[Abbreviation] Normal Voicing
Major [M] 1 - 3 - 5
Add ninth [(9)] 1 - 2 - 3 - 5
Sixth [6] 1 - (3) - 5 - 6
Sixth add ninth [6(9)] 1 - 2 - 3 - (5) - 6
Major seventh [M7] 1 - 3 - (5) - 7 or
1 - (3) - 5 - 7
Major seventh ninth [M7(9)] 1 - 2 - 3 - (5) - 7
Major seventh sharp eleventh [M7#11] 1 - 2 - 3 - #4 - (5) - 7 or
1 - (2) - 3 - #4 - 5 - 7
Flatted fifth [(b5)] 1 - 3 - b5
Major seventh flatted fifth [M7b5] 1 - 3 - b5 - 7
Suspended fourth [sus4] 1 - 4 - 5
Augmented [aug] 1 - 3 - #5
Major seventh augmented [M7aug] 1 - (3) - #5 - 7
Minor [m] 1 - b3 - 5
Minor add ninth [m(9)] 1 - 2 - b3 - 5
Minor sixth [m6] 1 - b3 - 5 - 6
Minor seventh [m7] 1 - b3 - (5) - b7
Minor seventh add ninth [m7(9)] 1 - 2 - b3 - (5) - b7
Minor seventh eleventh [m7_11] 1 - (2) - b3 - 4 - 5 - (b7)
Minor major seventh [mM7] 1 - b3 - (5) - 7
Minor major seventh ninth [mM7(9)] 1 - 2 - b3 - (5) - 7
Minor seventh flatted fifth [m7b5] 1 - b3 - b5 - b7
Minor major seventh flatted fifth [mM7b5] 1 - b3 - b5 - 7
Diminished [dim] 1 - b3 - b5
Diminished seventh [dim7] 1 - b3 - b5 - 6
Seventh [7] 1 - 3 - (5) - b7 or
1 - (3) - 5 - b7
Seventh flatted ninth [7(b9)] 1 - b2 - 3 - (5) - b7
Seventh flatted thirteenth [7b13] 1 - 3 - 5 - b6 - b7
Seventh ninth [7(9)] 1 - 2 - 3 - (5) - b7
Seventh sharp eleventh [7#11] 1 - 2 - 3 - #4 - (5) - b7 or
1 - (2) - 3 - #4 - 5 - b7
Seventh add thirteenth [7(13)] 1 - 3 - (5) - 6 - b7
Seventh sharp ninth [7(#9)] 1 - #2 - 3 - (5) - b7
Seventh flatted fifth [7b5] 1 - 3 - b5 - b7
Seventh augmented [7aug] 1 - 3 - #5 - b7
Seventh suspended fourth [7sus4] 1 - 4 - (5) - b7
One plus two plus five [1+2+5] 1 - 2 - 5
Chord (C) Display
CC
C(9) C(9)
C6 C6
C6(9) C6(9)
CM7 CM7
CM7(9) CM7(9)
CM7#11 CM7#11
C(b5) C(b5)
CM7b5 CM7b5
Csus4 Csus4
Caug Caug
CM7aug CM7aug
Cm Cm
Cm(9) Cm(9)
Cm6 Cm6
Cm7 Cm7
Cm7(9) Cm7(9)
Cm7_11 Cm7 11
CmM7 CmM7
CmM7(9) CmM7(9)
Cm7b5 Cm7b5
CmM7b5 CmM7b5
Cdim Cdim
Cdim7 Cdim7
C7 C7
C7(b9) C7(b9)
C7b13 C7b13
C7(9) C7(9)
C7#11 C7#11
C7(13) C7(13)
C7(#9) C7(#9)
C7b5C7b5
C7aug C7aug
C7sus4 C7sus4
C1+2+5 C
