Yamaha PSR-330 [83/90] Midi implementation chart
![Yamaha PSR-330 [83/90] Midi implementation chart](/views2/2009448/page83/bg53.png)
81
,,,,,,,,,,,,,QQQQQQQQQQQQQ¢¢¢¢¢¢¢¢¢¢¢¢¢
MIDI Implementation Chart
[Portable Keyboard] Date: 1997. 1. 31
Model: PSR-330
MIDI Implementation Chart
Version: 1.0
Function Transmitted Recognized Remarks
Basic Default 1~16 CH 1~16 CH (*0)
Channel Changed 1~16 CH 1~16 CH (*0)
Default Mode 3 (*0)
Mode Messages X X
Altered ***** X
Note 0~127 0~127
Number : True voice ***** 0~127
Velocity Note on O 9nH, v=1~127 O 9nH, v=1~127
Note off X 9nH, v=0 X 9nH, v=0 or 8nH
After key’s X X
Touch Ch’s X X
Pitch Bender O O
Control Change 0, 32 O (*1) O (*1) Bank select MSB, LSB
1 O O Modulation depth
6, 38 O O Data entry MSB, LSB
7 O O Volume
10 O O Pan
11 O O Expression
64 O O Sustain
66 X O Sostenuto
84 O O Portamento control
91 O O Reverb depth
96 X O RPN Data increment
97 X O RPN Data decrement
100, 101 O (*2) O (*2) RPN LSB, MSB
120 O O All sound off
121 X O (*3) Reset all controllers
Program O 0~127 O 0~127
Change : True # ***** 0~127
System Exclusive O (*4) O (*4)
System : Song Position X X
: Song Select X X
Common : Tune X X
System : Clock O O (*5)
Real Time : Commands O (*6) O (*6)
Aux : Local ON/OFF X X
: All Notes Off X O
Messages : Active Sense O O
: Reset X X
Mode 1: OMNI ON, POLY Mode 2 : OMNI ON, MONO O : Yes
Mode 3: OMNI OFF, POLY Mode 4 : OMNI OFF, MONO X : No
