Yamaha PSR-330 [53/90] Song recording procedure
![Yamaha PSR-330 [53/90] Song recording procedure](/views2/2009448/page53/bg35.png)
51
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
QQQQQQQQQQQQQQQQ
QQQQQQQQQQQQQQQQ
¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢
Song Recording
1
Set Up to Record
Before recording set up the PSR-330 as required: e.g. select the required voice(s),
effects, accompaniment style, accompaniment fingering mode, etc.
Song Recording Procedure
2
Engage the Record Ready Mode
Press the [RECORD] button to engage the record-ready mode. The [RECORD]
button indicator will light, the SONG menu will automatically be selected, and a
SONG number will appear on the top line of the display. The beat indicator dots will
flash at the currently set tempo, indicating that the record ready (synchro-start) mode
is engaged. Also, the frame surrounding the song MELODY and ACCOMPANI-
MENT track icons will flash, indicating that a MELODY and/or ACCOMPANIMENT
track must be selected before recording can begin.
• If the [RECORD] but-
ton is pressed while a
demonstration song
or cartridge song is
selected, the lowest-
numbered user song
which does not con-
tain any recorded
data will automatically
be selected. If other
user songs already
contain data, how-
ever, user song num-
ber 21 will be se-
lected.
• The following panel
setting changes will
occur when the record
ready mode is en-
gaged:
• The measure number
will be reset to “1”.
• If the Metronome
function is on (page
65), the metronome
will sound at the cur-
rent tempo.
• The REGISTRATION
MEMORY FREEZE
function will be turned
on (it cannot be turned
off while the record
mode is engaged).
• The SYNCHRO STOP
function wil be turned
off.
1
MELODY
1234
MELODY MELODY MELODY
ACCOM-
PANIMENT
VOICE VOICE VOICE
RHYTHM
1
BASS CHORD
1
CHORD
2
PAD PHRASE
1
PHRASE
2
FINGERING
REGISTRATION MULTI PAD
RHYTHM
2
LR2R1
21
VOICE L VOICE R2
46 51
UserSng1
REVERB TRANSPOSE
0
REPEAT
1
MEASURE
HARMONY TEMPO
116
SYNC
STOP
MINUS ONE
VOICE
STYLE
SONG
3
If Necessary, Select a User Song Number
If the desired user song is not already selected, use the [+] and [–] or number
buttons to select as required.
