68
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
QQQQQQQQQQQQQQQQ
QQQQQQQQQQQQQQQQ
¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢
MIDI Functions
■ Transmit Channel & Transmit Track
The PSR-330 can simultaneously transmit data on all 16 MIDI channels. The
Transmit Channel and Transmit Track functions determine what PSR-330 data is
transmitted via which MIDI channels.
● Transmit Channel
The “Tr.Ch” function selects a MIDI channel to which a PSR-330 track can be
assigned via the Transmit Track function, below. First select a transmit channel,
then the transmit track for that channel. Different tracks can be assigned to each of
the 16 MIDI channels. Any of the standard MIDI channels - 1 through 16 — can
be specified.
● Transmit Track
The “Tr.Trk” function selects the track to be transmitted via the transmit channel
specified by the Transmit Channel function, above. The available settings are as
follows:
01
Tr.Ch
r1
Tr.Trk
• The initial default
channel/track settings
are:
Channel 1: R1 voice.
Channel 2: L voice
Channel 11: R2 voice.
All other channels:
OFF.
• When a track is as-
signed to more than
one MIDI channel, the
data from that track is
transmitted via the
lowest-numbered
channel.
• To avoid MIDI loops
which can cause op-
erational errors, check
the PSR-330 Local
Control setting (page
70), and the MIDI
THRU settings of any
external MIDI devices.
• MIDI transmit track
settings will be re-
tained even after turn-
ing the power off. See
page 80 for the de-
tails.
~r1 R1 keyboard voice.
~r2 R2 keyboard voice
~~L L keyboard voice.
rH1 Auto accompaniment rhythm 1 track data.
rH2 Auto accompaniment rhythm 2 track data.
bAS Auto accompaniment bass track data.
CH1 Auto accompaniment chord 1 track data.
CH2 Auto accompaniment chord 2 track data.
PAd Auto accompaniment pad track data.
PH1 Auto accompaniment phrase 1 track data.
PH2 Auto accompaniment phrase 2 track data.
oFF No data transmitted.
