Overall Functions
■ Metronome
When turned “on” the PSR-330 metronome will sound during AUTO ACCOMPA-
NIMENT playback as well as SONG playback and recording.
■ Split Voice Split Point
See page 18.
■ Accompaniment Split Point
See page 27.
■ Fingering Mode
See page 28.
on
Metronom
■ Voice Set
The VOICE SET feature brings out the best in each individual voice by automati-
cally setting a range of important voice-related parameters whenever an R1 panel
voice (voice numbers 1 … 136) is selected. The parameters that may be set by the
VOICE SET feature are listed below. This function lets you turn VOICE SET on or off,
as required.
• The Voice Set func-
tion is on by default
when the power is ini-
tially turned on.
on
VoiceSet
● Voice Set parameter list
• R1 Voice (Volume, octave, pan, reverb send level)
• R2 Voice (Voice number, volume, octave, pan, reverb send level)
• L Voice (Voice number, volume, octave, pan, reverb level)
• Reverb ON/OFF
• Harmony type, volume
