MIDI Functions
● Receiving Bulk Data
The PSR-330 will automatically receive compatible bulk data from an external
MIDI device as long as no auto accompaniment, multi pad, or song recording/
playback operation is in progress. “BkRcv” will appear on the display during
reception, then “End” will appear briefly when all data has been received.
• No other operations
can be performed dur-
ing bulk dump recep-
tion.
• If an error is encoun-
tered during bulk data
reception, “Blk Err”
will appear on the dis-
play, and song and
registration memory
will be cleared.
• When a bulk dump is
received, the received
data replaces any
data that was previ-
ously in the PSR-330
memory.
BkRcv
End
■ Initial Data Send
Transmits all current panel settings to a second PSR-330 or a MIDI data storage
device. To send the initial data select the “InitSnd?” function, then press the [+] (YES)
button. “Sure?” will appear on the display. Press the [+] (YES) again to begin
transmission of the initial data.
YES
InitSnd?
