75
,,,,,,,,,,,,,,QQQQQQQQQQQQQQ¢¢¢¢¢¢¢¢¢¢¢¢¢¢
Voice List
PERCUSSIVE
115 0 112 113 Agogo 1
116 0 112 115 Woodblock 1
117 0 112 116 Taiko Drum 1
118 0 112 117 Melodic Tom 1
119 0 112 118 Synth Drum 1
120 0 112 119 Reverse Cymbal 1
SOUND EFFECTS
121 0 112 122 Seashore 2
122 0 112 123 Bird Tweet 2
123 0 112 124 Telephone Ring 1
124 0 112 125 Helicopter 2
125 0 112 126 Applause 2
126 0 112 127 Gunshot 1
DRUM KITS
127 127 0 0 Standard Kit 1 1
128 127 0 1 Standard Kit 2 1
129 127 0 8 Room Kit 1
130 127 0 16 Rock Kit 1
131 127 0 24 Electronic Kit 1
132 127 0 25 Analog Kit 1
133 127 0 27 Dance Kit 1
134 127 0 32 Jazz Kit 1
135 127 0 40 Brush Kit 1
136 127 0 48 Classic Kit 1
Voice
Bank Select MIDI
Voice Name
Number
Number
MSB LSB
Program of Notes
Number Used
068 0 112 107 Koto 1
069 0 112 46 Harp 2
070 0 112 104 Sitar 2
BRASS
071 0 112 56 Trumpet 1
072 0 112 59 Muted Trumpet 1
073 0 112 57 Trombone 1
074 0 113 57 Trombone Section 2
075 0 112 60 French Horn 1
076 0 112 58 Tuba 1
077 0 112 61 Brass Section 2
078 0 113 61 Brass+Sax 2
079 0 114 61 Brass+Trombone 2
080 0 115 61 Brass+Trumpet 2
081 0 112 62 Synth Brass 1 2
082 0 113 63 Synth Brass 2 2
REED
083 0 112 64 Soprano Sax 1
084 0 112 65 Alto Sax 1
085 0 112 66 Tenor Sax 1
086 0 112 67 Baritone Sax 1
087 0 113 66 Sax+Clarinet 2
088 0 114 66 Sax+Trombone 2
089 0 112 68 Oboe 1
090 0 112 69 English Horn 1
091 0 112 70 Bassoon 1
092 0 112 71 Clarinet 1
093 0 112 22 Harmonica 1
094 0 112 111 Shanai 1
095 0 112 109 Bagpipe 2
PIPE
096 0 112 72 Piccolo 1
097 0 112 73 Flute 1
098 0 112 75 Pan Flute 1
099 0 112 74 Recorder 1
100 0 112 76 Blown Bottle 2
101 0 112 77 Shakuhachi 1
102 0 112 78 Whistle 1
103 0 112 79 Ocarina 1
SYNTH LEAD
104 0 112 80 Square Lead 2
105 0 112 81 Sawtooth Lead 2
106 0 112 85 Voice Lead 2
107 0 112 98 Crystal 2
108 0 112 100 Brightness 2
109 0 113 81 Analog Lead 2
SYNTH PAD
110 0 112 88 Fantasia 2
111 0 113 100 Bell Pad 2
112 0 112 89 Xenon Pad 2
113 0 112 91 Angels 2
114 0 114 81 Dark Moon 2
Voice
Bank Select MIDI
Voice Name
Number
Number
MSB LSB
Program of Notes
Number Used
