MIDI Functions
■ Receive Channel & Receive Mode
The PSR-330 can simultaneously receive data on all 16 MIDI channels, allowing
it to function as a 16-channel multi-timbral tone generator. The Receive Channel and
Receive Mode functions determine how each channel will respond to received MIDI
data.
● Receive Channel
The “Rcv.Ch” function selects a MIDI channel to which a receive mode is to be
assigned via the Receive Mode function, below. First select a receive channel, then
the receive mode for that channel. Any of the standard MIDI channels — 1 through
16 — can be specified.
● Receive Mode
The “Rcv.Mod” function specifies the receive mode for the channel selected via the
Receive Channel function, above. The receive mode settings are as follows:
• MIDI receive mode
settings will be re-
tained even after turn-
ing the power off. See
page 80 for the de-
tails.
01
Rcv.Ch
nor
Rcv.Mod
nor “Normal”. Received MIDI data is sent directly to the PSR-330 tone
generator. If all channels are set to “nor”, the PSR-330 functions as a 16-
channel multi-timbral tone generator.
oFF No MIDI data is received on channels set to “oFF”.
~rE “Remote”. Received MIDI data is handled in the same way as data
generated by the PSR-330’s own keyboard. In other words, a remote
keyboard could be used to control the PSR-330 AUTO ACCOMPANI-
MENT functions, etc.
