44
,,,,,,,,,,,,,,,,
,,,,,,,,,,,,,,,,
QQQQQQQQQQQQQQQQ
QQQQQQQQQQQQQQQQ
¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢
¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢¢
Song Playback
Use the following procedure to play back the PSR-330’s internal demonstration songs as well
as songs you record yourself (see “Song Recording”, page 50).
1
Select the Song Menu
Press the [SONG] button to select the SONG menu (the triangular indicator will
appear next to “SONG” to the right of the display). The number and name of the
currently selected song will appear on the top line of the display, and the song track
and volume icons near the bottom of the display will appear framed.
Song Playback Procedure
2
Select a SONG Number
If necessary, use the [–] and [+] or number buttons to select the SONG number you
want to play. The SONG number can also be incremented by pressing the [SONG]
button: press briefly to increment by one, or hold for continuous incrementing.
1
MELODY
1234
MELODY MELODY MELODY
ACCOM-
PANIMENT
VOICE VOICE VOICE
RHYTHM
1
BASS CHORD
1
CHORD
2
PAD PHRASE
1
PHRASE
2
FINGERING
REGISTRATION MULTI PAD
RHYTHM
2
LR2R1
01
VOICE L VOICE R2 VOICE R1
46 51 1
DancePop
REVERB TRANSPOSE
0
REPEAT
1
MEASURE
HARMONY TEMPO
116
SYNC
STOP
MINUS ONE
VOICE
STYLE
SONG
123
456
78
0
9
NO YES
02
WåRock
