Yamaha PSR-330 [79/90] Voice list
![Yamaha PSR-330 [79/90] Voice list](/views2/2009448/page79/bg4f.png)
77
,,,,,,,,,,,,,,QQQQQQQQQQQQQQ¢¢¢¢¢¢¢¢¢¢¢¢¢¢
Synth Effects
233 0 0 96 FX 1 (rain) 2
234 0 0 97 FX 2 (soundtrack) 2
235 0 0 98 FX 3 (crystal) 2
236 0 0 99 FX 4 (atmosphere) 2
237 0 0 100 FX 5 (brightness) 2
238 0 0 101 FX 6 (goblins) 2
239 0 0 102 FX 7 (echoes) 2
240 0 0 103 FX 8 (sci-fi) 2
Ethnic
241 0 0 104 Sitar 1
242 0 0 105 Banjo 1
243 0 0 106 Shamisen 1
244 0 0 107 Koto 1
245 0 0 108 Kalimba 1
246 0 0 109 Bagpipe 2
247 0 0 110 Fiddle 1
248 0 0 111 Shanai 1
Percussive
249 0 0 112 Tinkle Bell 2
250 0 0 113 Agogo 1
251 0 0 114 Steel Drums 2
252 0 0 115 Woodblock 1
253 0 0 116 Taiko Drum 1
254 0 0 117 Melodic Tom 1
255 0 0 118 Synth Drum 1
256 0 0 119 Reverse Cymbal 1
Sound Effects
257 0 0 120 Guitar Fret Noise 1
258 0 0 121 Breath Noise 1
259 0 0 122 Seashore 2
260 0 0 123 Bird Tweet 2
261 0 0 124 Telephone Ring 1
262 0 0 125 Helicopter 2
263 0 0 126 Applause 2
264 0 0 127 Gunshot 1
Voice
Bank Select MIDI
Voice Name
Number
Number
MSB LSB
Program of Notes
Number Used
Voice List
