Song Recording
Clearing Song Data
This function makes it possible to clear unneeded data from the PSR-330 SONG
memory.
Clearing an Entire Song
While the SONG record-ready or rehearsal mode is engaged use the SUB MENU
[▲] and [▼] buttons to select the “SongClr?” function, then press the [+] (YES)
button: “Sure?” will appear on the display. Press the [+] (YES) button a second time
to actually clear the currently selected user song (the demonstration songs and
cartridge songs cannot be cleared). Press [–] (NO) if you want to abort the clear
operation.
Clearing Selected Melody Tracks
While the SONG record-ready or rehearsal mode is engaged use the SUB MENU
[▲] and [▼] buttons to select the “TrkClr?” function. The SONG tracks icons
corresponding to MELODY tracks which contain data will flash (the ACCOMPANI-
MENT track cannot be cleared — neither can tracks in demonstration or cartridge
songs). Use the TRACK buttons to select track(s) you want to clear (frames will
appear continuously around the selected tracks). Once the desired tracks have been
selected, press the [+] (YES) button: “Sure?” will appear on the display. Press the [+]
(YES) button a second time to actually clear the currently selected track(s). Press
[–] (NO) if you want to abort the clear operation.
YEs
SongClr?
Sure?
78
0
9
MELODY
1234
MELODY MELODY MELODY
ACCOM-
PANIMENT
VOICE VOICE VOICE
RHYTHM
1
BASS CHORD
1
CHORD
2
PAD PHRASE
1
PHRASE
2
FINGERING
REGISTRATION MULTI PAD
RHYTHM
2
LR2R1
YEs
VOICE L VOICE R2
46 51
TrkClr?
REVERB TRANSPOSE
0
REPEAT
1
MEASURE
HARMONY TEMPO
116
SYNC
STOP
MINUS ONE
OVERALL
REGIST
MEMORY
DIGITAL
EFFECT
MIDI
MULTI PAD
VOICE R1
1
1
MINUS ONE
MELODY
1234
MELODY MELODY MELODY
ACCOM-
PANIMENT
VOICE VOICE VOICE
LR2R1
MINUS ONE
