English | 19
Bosch Power Tools 2 609 932 800 | (8.4.11)
Sawing with Parallel Guide (see figure D)
The parallel guide 12 enables exact cuts along a workpiece
edge and cutting strips of the same dimension.
Loosen wing bolt 7 and slide the scale of the parallel guide 12
through the guide in the base plate 15. Adjust the desired cut-
ting width as the scale setting at the respective cutting mark 9
or 10; see Section “Cutting Marks”. Tighten wing bolt 7 again.
Sawing with Auxiliary Guide (see figure E)
For sawing large workpieces or straight edges, a board or
strip can clamped to the workpiece as an auxiliary guide; the
base plate of the circular saw can be guided alongside the aux-
iliary guide.
Sawing with Guide Rail (GKS 55 GCE) (see figure F–G)
The guide rail 29 is used to carry out straight cuts.
The rubber lip on the guide rail acts as a splinter guard; it pre-
vents fraying of the surface while sawing wooden materials.
For this, the teeth of the saw blade must face directly against
the rubber lip.
Prior to the very first cut, the rubber lip must be adapted with
the guide rail 29 to the circular saw being used. For this, place
the guide rail 29 over its complete length on a workpiece. Ad-
just a cutting depth of approx. 9 mm and the saw blade to a ze-
ro degree angle. Switch the circular saw on and guide it uni-
formly and with light feed in the cutting direction.
Two guide rails can be connected to one with use of the con-
nection piece 30. Clamping is carried out with the four screws
located in the connection piece.
Maintenance and Service
Maintenance and Cleaning
f Before any work on the machine itself, pull the mains
plug.
f For safe and proper working, always keep the machine
and ventilation slots clean.
The retracting blade guard must always be able to move freely
and retract automatically. Therefore, always keep the area
around the retracting blade guard clean. Remove dust and
chips by blowing out with compressed air or with a brush.
Saw blades that are not coated can be protected against cor-
rosion with a thin coat of acid-free oil. Before use, the oil must
be removed again, otherwise the wood will become soiled.
Resin and glue residue on the saw blade produces poor cuts.
Therefore, clean the saw blade immediately after use.
If the machine should fail despite the care taken in manufac-
turing and testing procedures, repair should be carried out by
an after-sales service centre for Bosch power tools.
In all correspondence and spare parts order, please always in-
clude the 10-digit article number given on the type plate of
the machine.
After-sales Service and Customer Assistance
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Our customer service representatives can answer your ques-
tions concerning possible applications and adjustment of
products and accessories.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: +44 (0844) 736 0109
Fax: +44 (0844) 736 0146
E-Mail: boschservicecentre@bosch.com
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: +353 (01) 4 66 67 00
Fax: +353 (01) 4 66 68 88
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: +61 (01300) 307 044
Fax: +61 (01300) 307 045
Inside New Zealand:
Phone: +64 (0800) 543 353
Fax: +64 (0800) 428 570
Outside AU and NZ:
Phone: +61 (03) 9541 5555
www.bosch.com.au
Republic of South Africa
Customer service
Hotline: +27 (011) 6 51 96 00
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: +27 (011) 4 93 93 75
Fax: +27 (011) 4 93 01 26
E-Mail: bsctools@icon.co.za
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: +27 (031) 7 01 21 20
Fax: +27 (031) 7 01 24 46
E-Mail: bsc.dur@za.bosch.com
OBJ_BUCH-244-004.book Page 19 Friday, April 8, 2011 10:03 AM
