VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
39
39
Command – NET-GATE
Command Type – Communication
Command Name
Permission
Transparency
Set:
NET-GATE
Administrator
-
Get:
NET-GATE?
End User
-
Description
Syntax
Set:
Set Gateway IP
#NET-GATE␠ P1 ␍
Get :
Get Gateway IP
#NET-GATE?␍
Response
Set: ~nn @ NET-GATE ␠ P1 ␠OK␍␊
Get: ~nn @ NET-GATE ␠ ip_address ␍␊
Parameters
P1 (valid IP address)=xxx.xxx.xxx.xxx
Notes
A network gateway connects the device via another network and maybe over the Internet. Be careful of
security problems. For proper settings consult your network administrator
Command – NET-MASK
Command Type – Communication
Command Name
Permission
Transparency
Set:
NET-MASK
Administrator
-
Get:
NET-MASK?
End User
-
Description
Syntax
Set:
Set device subnet mask
#NET-MASK␠ net_mask ␍
Get :
Get device subnet mask
#NET-MASK? ␍
Response
Set: ~nn @NET-MASK ␠ P1 ␠ OK␍␊
Get: ~nn @NET-MASK ␠ net_mask ␍␊
Parameters
P1 (valid IP address)=xxx.xxx.xxx.xxx
Response triggers
The subnet mask limits the Ethernet connection within the local network.
For proper settings consult your network administrator.
