![Kramer VP-439 Руководства по эксплуатации онлайн [45/52] 140319](/views2/1153513/page45/bg2d.png)
40
VP-439 - The RS-232/Ethernet (UDP) Communication Protocol
Command – NET-DHCP
Command Type – Communication
Command Name
Permission
Transparency
Set:
NET-DHCP
Administrator
-
Get:
NET-DHCP?
End User
-
Description
Syntax
Set:
Set DHCP mode
#NET-DHCP␠ P1 ␍
Get :
Get DHCP mode
#NET-DHCP?␍
Response
Set: ~nn @ NET-DHCP ␠ P1 ␠ OK␍␊
Get: ~nn @ NET-DHCP ␠ mode ␍␊
Parameters
P1 – 0=Static IP; 1=DHCP
0 – Use static IP.
1 – Use DHCP. If unavailable, use IP as above.
Notes
Connecting Ethernet to devices with DHCP may take more time in some networks.
To connect with a randomly assigned IP by DHCP, specify the device DNS name (if available) using the
command “NAME”. You can also get an assigned IP by direct connection to USB or RS-232 protocol port
if available.
For proper settings consult your network administrator.
Command – ROUTE
Command Type –
Command Name
Permission
Transparency
Set:
ROUTE
End User
-
Get:
ROUTE?
End User
-
Description
Syntax
Set:
Set layer routing
# ROUTE ␠ P1,P2,P3 ␍
Get :
Get layer routing
# ROUTE? ␠ P1,P2 ␍
Response
~ nn@ ROUTE ␠ P1,P2,P3 ␍␊
Parameters
P1 (Layer number) –12=Video+Audio
P2 – 1=Scaler
P3 – video inputs (0~2) – 0=HDMI; 1=PC; 2=Video (CV);
Notes
This command replaces all other routing commands.
