ASUS H81-GAMER
1-7
1.4 System memory
1.4.1 Overview
ThismotherboardcomeswithfourDoubleDataRate3(DDR3)DualInlineMemoryModule
(DIMM)sockets.ADDR3moduleisnotcheddifferentlyfromaDDRorDDR2module.DO
NOTinstallaDDRorDDR2memorymoduletotheDDR3slot.
H81-GAMER
H81-GAMER 240-pin DDR3 DIMM sockets
DIMM_A1
DIMM_A2
DIMM_B1
DIMM_B2
1.4.2 Memorycongurations
Youmayinstall1GB,2GB,4GB,and8GBunbufferednon-ECCDDR3DIMMsintothe
DIMMsockets.Youcanrefertotherecommendedmemorypopulationbelow.
AccordingtoIntel
®
CPUspec,DIMMvoltagebelow1.65Visrecommendedtoprotectthe
CPU.
Combination
Recommended
DIMM_A1 DIMM_A2 DIMM_B1 DIMM_B2
1 SS
2 SS
3 SS SS
4 DS
5 DS
6 DS DS
7 SS SS SS SS
SS:Single-sidedmemory DS:Double-sidedmemory
