1-14
Chapter 1: Product introduction
10. USB 2.0 ports 3 and 4.These4-pinUniversalSerialBus(USB)portsareforUSB
2.0/1.1devices.
11. USB 3.0 ports 1 and 2.Thesetwo9-pinUniversalSerialBus(USB)portsareforUSB
3.0/2.0devices.
• DONOTconnectakeyboard/mousetoanyUSB3.0portwheninstallingWindows
®
operating system.
• DuetoUSB3.0controllerlimitation,USB3.0devicescanonlybeusedunder
Windows
®
OSenvironmentandaftertheUSB3.0driverinstallation.
• USB3.0devicescanonlybeusedasdatastorageonly.
• WestronglyrecommendthatyouconnectUSB3.0devicestoUSB3.0portsforfaster
andbetterperformanceforyourUSB3.0devices.
12. USB 2.0 ports 5 and 6.These4-pinUniversalSerialBus(USB)portsareforUSB
2.0/1.1devices.
13. DVI-D port. ThisportisforanyDVI-Dcompatibledevice.DVI-Dcan’tbeconvertedto
outputRGBSignaltoCRTandisn’tcompatiblewithDVI-I.
14. PS/2 keyboard port (purple).ThisportisforaPS/2keyboard.
1.7.2 Internal connectors
1. CPU and chassis fan connectors (4-pin CPU_FAN, CHA_FAN1, CHA_FAN2)
Connectthefancablestothefanconnectorsonthemotherboard,ensuringthatthe
black wire of each cable matches the ground pin of the connector.
Donotforgettoconnectthefancablestothefanconnectors.Insufcientairowinside
thesystemmaydamagethemotherboardcomponents.Thesearenotjumpers!Donot
placejumpercapsonthefanconnectors!TheCPU_FANconnectorsupportsaCPUfanof
maximum1A(12W)fanpower.
CHA_FAN1
+5V
CHA FAN IN
CHA FAN PWR
GND
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
A
B
CPU_FAN
A
CHA_FAN2
GND
CHA FAN PWR
CHA FAN IN
+5V
C
B
C
H81-GAMER
H81-GAMER Fan connectors
